Panasonic DP-101A-N-P-J Sensor: Features, Applications, and Advantages

What is the DP-101A-N-P-J Pressure Sensor?

The Panasonic DP-101A-N-P-J is an industrial sensor specifically designed for precise pressure measurements. Its compact design, wide measurement range, and high accuracy make it a critical component in automation systems. This sensor ensures reliability and precision in various industries.

Technical Specifications

The technical specifications of the DP-101A-N-P-J sensor are as follows:

• Pressure Range: 0 to 1 MPa
• Accuracy: ±%0.2 FS
• Output Type: Digital
• Operating Temperature: -10°C to 50°C
• Mounting Type: Panel or surface mount
• Power Supply: 12-24V DC

These features enable the sensor to deliver high performance in various applications.

Applications

The DP-101A-N-P-J sensor has a wide range of applications. Key usage areas include:

1. Industrial Automation: Ideal for precise measurements in pressure control systems.
2. Medical Devices: Used in respiratory devices and other medical equipment.
3. Automotive Industry: Commonly used for in-engine pressure measurement and hydraulic systems.
4. Food Industry: Compatible with hygienic design requirements.

Advantages of the Panasonic DP-101A-N-P-J Sensor

The advantages of this sensor include:

• High Accuracy: Provides reliable data through precise measurements.
• Compact Design: Easily mountable in confined spaces.
• Wide Operating Temperature Range: Stable performance even in challenging environments.
• Durability: Made from high-quality materials for long life.
• Ease of Use: User-friendly interface and easy installation.

Installation and Usage of the DP-101A-N-P-J Sensor

Installation Guide

• Panel Mounting: Easily fits into panel slots.
• Connections: Power supply and data output terminals should be connected according to specified standards.
• Calibration: Must be calibrated with a correct pressure reference during the initial setup.

Calibration Process

Calibrating the DP-101A-N-P-J sensor is essential for accurate measurements. Follow these steps:

1. Connect the sensor to a power source.
2. Apply reference pressure using a calibration device.
3. Adjust the reference value on the sensor display.

Purchasing Process

Price and Stock Availability

The Panasonic DP-101A-N-P-J sensor can be obtained through Panasonic’s authorized distributors. The DP-101A-N-P-J price varies depending on the order quantity and distributor. For updated stock availability and pricing information, visit Panasonic’s official website or the platforms of authorized distributors.

Buying Tips

• Authorized Distributors: Purchase from authorized distributors to ensure original product warranty.
• Online Stores: Opt for reputable e-commerce sites.
• Request a Quote: Ask distributors for quotes to get price advantages on bulk orders.

Frequently Asked Questions (FAQs) about the DP-101A-N-P-J Sensor

1. In which industries can I use the DP-101A-N-P-J sensor?

This sensor is widely used in industrial automation, medical devices, automotive, and food industries.

2. What is the accuracy level of the DP-101A-N-P-J?

The sensor operates with an accuracy of ±%0.2 FS, ensuring high precision.

3. Is the installation process complicated?

No, the sensor is designed for easy installation with panel or surface mounting options.

4. What is the operating temperature range of the sensor?

The DP-101A-N-P-J sensor works seamlessly within a range of -10°C to 50°C.

5. How often should calibration be performed?

Calibration is recommended during the initial setup and during regular maintenance.

6. What is the price of the DP-101A-N-P-J?

Pricing depends on the distributor and order quantity. Contact distributors for updated prices.

Conclusion

The Panasonic DP-101A-N-P-J pressure sensor offers an excellent solution for industrial automation and other applications, with its high accuracy, durability, and ease of use. With its technical specifications and advantages, this sensor is suitable for various industries. We recommend reaching out to authorized distributors for a smooth purchasing and installation process.
