Panasonic DP-101-E-P Sensor: Technical Specifications, Applications, and Advantages

What is the Panasonic DP-101-E-P Sensor?

The Panasonic DP-101-E-P sensor is specifically developed for industrial applications that require precise pressure measurements. With digital output features, easy installation options, and a durable design, it delivers consistent performance even in challenging operating conditions. This sensor quickly and accurately measures pressure values, contributing to the optimization of systems.

Technical Specifications

The technical specifications of the DP-101-E-P sensor are as follows:

• Pressure Range: Measures from -100 kPa to 1 MPa.
• Accuracy: ±%0.5 FS
• Output Type: Digital (PNP/NPN)
• Operating Temperature: -10°C to 50°C
• Power Supply: 12-24V DC
• Mounting Options: Panel or surface mounting
• Dimensions: Compact design (24 x 30 x 10 mm)

Applications

The DP-101-E-P pressure sensor can be used in a variety of industrial and commercial fields. Key application areas include:

1. Industrial Automation: Used in systems requiring pressure control, especially in pneumatic and hydraulic systems.
2. Medical Devices: Provides reliable measurements in respiratory devices, medical test equipment, and other applications.
3. Automotive Industry: Used for in-engine pressure measurements, fuel systems, and air conditioning systems.
4. Food Industry: Models compatible with hygienic designs can be used in production processes.
5. Electronics Manufacturing: Ensures precise measurements in air flow control and vacuum systems.

Advantages of the DP-101-E-P Sensor

The DP-101-E-P sensor provides an effective solution for users with the following advantages:

• High Accuracy: Enables efficient operation of critical systems with precise measurements.
• Fast Response Time: Quickly detects pressure changes, optimizing system response times.
• Durability: Resistant to challenging working conditions and long-lasting.
• Compact Design: Easily mountable in tight spaces due to its small size.
• User-Friendly Interface: Digital display and simple connection options make it easy to use.
• Wide Operating Temperature Range: Provides stable performance in various environmental conditions.

Installation and Usage Guide

Installation Process

• Panel or Surface Mounting: The DP-101-E-P sensor is suitable for panel or surface mounting. During panel mounting, the sensor is placed in appropriate slots and connection points are secured.
• Electrical Connections: Power supply connections and output terminals must be connected correctly. Ensure cables are securely fastened.
• Calibration: During initial setup, the sensor should be calibrated using compatible pressure references.

Usage Tips

• Instant pressure values can be monitored on the sensor’s digital display.
• Regular maintenance and cleaning enhance the sensor’s performance and extend its lifespan.

Calibration Process

The calibration process is crucial for ensuring the Panasonic DP-101-E-P sensor performs accurate measurements. Follow these steps to complete calibration:

1. Connect the Sensor to a Power Source: Ensure the sensor is powered.
2. Apply Reference Pressure: Use an appropriate pressure calibration device to apply reference pressure to the sensor.
3. Adjust Values: Adjust the values displayed on the sensor to match the reference pressure.

Purchasing the DP-101-E-P Sensor

Price and Stock Availability

The price of the DP-101-E-P sensor varies depending on order quantity and distributors. For updated price information and stock availability, you can contact Panasonic’s authorized distributors.

Buying Tips

• Authorized Distributors: Purchase from Panasonic-authorized distributors to ensure original product warranty.
• Online Stores: Shop from reliable e-commerce platforms to enjoy fast delivery benefits.
• Request a Quote: Get a price advantage on bulk orders by requesting quotes from distributors.

User Reviews and Feedback

Customers using the DP-101-E-P sensor generally provide positive feedback on the product’s performance, durability, and ease of use. Users particularly appreciate the sensor’s high accuracy and fast response time.

Frequently Asked Questions (FAQs) About the DP-101-E-P Sensor

1. In which industries can the DP-101-E-P sensor be used?

It is widely used in industrial automation, medical devices, automotive, and food industries.

2. What is the accuracy of the sensor?

The DP-101-E-P sensor operates with an accuracy of ±%0.5 FS, ensuring high precision.

3. Is the installation process easy?

Yes, the sensor offers easy installation with its compact design and user-friendly mounting options.

4. How often should calibration be performed?

Calibration is recommended during initial setup and at regular maintenance intervals.

5. How much does the sensor cost?

The price depends on the distributor and order quantity. Contact distributors for detailed information.

6. What is the sensor’s operating temperature range?

The sensor provides stable performance between -10°C and 50°C.

Conclusion

The Panasonic DP-101-E-P pressure sensor offers an effective solution for industrial automation and other applications with its high accuracy, durability, and user-friendly features. With its technical specifications, advantages, and wide range of applications, this sensor is an ideal choice for your reliable measurement needs. We recommend contacting authorized distributors for a smooth purchasing process.
